Description
Marine LED Navigation Signal lights for all vessels ≥50M in length 8 Watt,56, CCS approval
SKU: JN-NAV-008S-S-S
Features of the Marine LED Navigation Signal lights for all vessels ≥50M in length 8 Watt,56, CCS approval
| Product SKU | JN-NAV-008S-S-S |
|---|---|
| Power Consumption | 8 |
| Input Voltage | 100~240VAC |
| IP Rating | 56 |
| Certifications | CCS approval |
| Housing Colour | Black |
| Housing Material | PA+GF housing, PC lampshade, Stainless steel lens hood |
| Socket/Base Type | 4 hole mounting (Φ10~Φ12 cable entry) |
| Warranty Period (Years) | 3 |
| IMPA Code | 371121 |
| Visibility Range (NM) | 3 NM |
| Level Arc | 112.5° |
| Signal Color | Green |
| Output Voltage | 12-24VDC |
| LED Driver | Constant Current |
| Particulars | CCS approved for vessels ≥50M, IP56 rated |
| Working Temperature Range | -25°C to +55°C |
| Product Dimensions (mm) | 215x215x215 |
|---|---|
| Net Weight (kg) | 1.5 kg |
| Export Carton Dimensions (mm) | 300x250x250 |
| Products per Carton | 1 |
| Export Carton Gross Weight (kg) | 3 kg |
| Fixture Height (mm) | 215 |
| Fixture Width (mm) | 215 |
| Fixture Length (mm) | 285 |
Specification Details
Single Lens LED Starboard Light for all vessels ≥50M in length
