Description
ATEX explosion proof LED lights 3W-15W Watt, lm, , IP66, ,2700K-7000K
SKU: JN-ATEX-Exit2Series
Features of the ATEX explosion proof LED lights 3W-15W Watt, lm, , IP66, ,2700K-7000K
| Product SKU | JN-ATEX-Exit2Series |
|---|---|
| Power Consumption | 20 |
| Input Voltage | AC100-277V, 50/60Hz; DC12-36V |
| Input Frequency | 50/ 60Hz |
| Light Color | 2700K-7000K |
| LED Type | SMD |
| Total Lumens Output | 2800 |
| Luminous Efficacy (lm/W) | 140 |
| Power Factor | >0.95 |
| IK Impact Rating | IK08 |
| Housing Colour | Grey |
| Housing Material | Glass fibre reinforced polyester resin/PC |
| Warranty Period (Years) | 5 |
| IP Rating | IP66 |
| Color Rendering Index | >70 |
| Beam Angle (°) | 30°, 60°, 90°, 120° |
| Dimming Capability | Non-dimmable |
| ATEX Standard | II 2 G Ex eb mb IIC T6...T4 Gb II 2 D Ex tb IIIC T80°C...T100°C Db II 3 G Ex ec IIC T6...T3 Gc II 2 D Ex tb IIIC T85℃...T103℃ Db |
| IECEx Standard | E db eb mb q IIC T5/T6 Gb; Ex tb IIIC 80°C/95°C Db |
| UL Standard | Class I, Division 2, Groups A, B, C, D Class I, Zone 1, AEx eb mb IIC T6...T4 Gb Class II, Division 1, Groups E, F, G |
| Retilap Standard | Esquema 5 RETILAP |
| Other Standards | ABS certified 1000 hours salt spray |
| Fixture Shape | Rectangular |
| Fixture Height (mm) | 99 mm |
| Fixture Width (mm) | 270 mm |
| Fixture Length (mm) | 476 mm |
| Net Weight (kg) | 4.32 kg |
| Temperature Class | T6 |
| Gas Group | IIC |
| Protection Type | Ex eb mb |
| Zone Classification | Zone 1 & 2 |
| IK Rating with Wire Guard | IKIK10 (with wire guard) |
| Working Temperature Range | -20°C to +45°C |
| Working Humidity Range | 10-95% RH |
| Lifespan (Hours) | 80,000 hours |
| Product Dimensions (mm) | 99×270×476mm |
|---|---|
| Net Weight (kg) | 4.32 kg |
| Export Carton Dimensions (mm) | 550x300x190 |
| Products per Carton | 1 |
| Export Carton Gross Weight (kg) | 5 kg |
Specification Details
This versatile product can be used as a lighting luminaire, emergency lighting luminaire, escape route sign luminaire. Available mounting method: wall mounting., ceiling mounting, pendant mounting. 3 hours back-up operation. Central locking available (optional). Cable entry size: M25x1.5, 3/4 NPT. Label content can be customized (labels in various languages and with different exit signs are available).
