Description
ATEX explosion proof LED lights 20-200 Watt, 2,600-26,000lm, 40°/ 60°/ 90°/ 120°, IP66, ,
SKU: JNFL-ATEX-ModelF
Features of the ATEX explosion proof LED lights 20-200 Watt, 2,600-26,000lm, 40°/ 60°/ 90°/ 120°, IP66, ,
| Product SKU | JNFL-ATEX-ModelF |
|---|---|
| Power Consumption | 20 |
| Input Voltage | AC120-277V, 50/60Hz, DC36V |
| Input Frequency | 50/ 60Hz |
| Light Color | 2200K-7000K |
| LED Type | SMD |
| Total Lumens Output | 2,600-26,000 |
| Luminous Efficacy (lm/W) | 140 |
| Power Factor | >0.95 |
| IK Impact Rating | 07 (without wire guard) |
| Housing Colour | Grey |
| Housing Material | Copper free aluminium, tempered glass |
| Warranty Period (Years) | 5 |
| IP Rating | IP66 |
| Color Rendering Index | >70 |
| Beam Angle (°) | 40°, 60°, 90°, 120° |
| Dimming Capability | Non-dimmable |
| ATEX Standard | Flame-proof type: Gas: II 2 G Ex db IIB T6...T4 Gb; Dust: II 2 D Ex tb IIIC T80°...120°C Db IP66; Flame-proof and increased safe type: Gas: II 2 G Ex db eb IIB T6...T4 Gb; Dust: II 2 D Ex tb IIIC T80°C...120°C Db IP66 |
| IECEx Standard | Ex eb mb IIC T6...T4 Gb Ex tb IIIC T80°C...T100°C Db Ex ec IIC T6...T3 Gc Ex tb IIIC T85℃...T103℃ Db |
| UL Standard | Class I, Division 2, Groups A, B, C, D Class I, Zone 1, AEx eb mb IIC T6...T4 Gb Class II, Division 1, Groups E, F, G |
| Retilap Standard | Esquema 5 RETILAP |
| Other Standards | EN 60079-0/ EN 60079-1/ EN 60079-31/ EN 60079-7 |
| Fixture Shape | Rectangular |
| Fixture Height (mm) | 103 mm |
| Fixture Width (mm) | 270 mm |
| Fixture Length (mm) | 380 mm |
| Net Weight (kg) | 4.4 kg |
| Temperature Class | T6 |
| Gas Group | IIC |
| Protection Type | Ex eb mb |
| Zone Classification | Zone 1 & 2 |
| IK Rating with Wire Guard | IK09 (with wire guard) (with wire guard) |
| Working Temperature Range | -20°C to +45°C |
| Working Humidity Range | 10-95% RH |
| Lifespan (Hours) | 80,000 hours |
| Product Dimensions (mm) | 103×270×380mm |
|---|---|
| Net Weight (kg) | 4.4 kg |
| Export Carton Dimensions (mm) | 386x330x220 |
| Products per Carton | 1 |
| Export Carton Gross Weight (kg) | 14.5 kg |
Specification Details
Available mounting method: wall mounting. With hinged access door. Supplied with 3/4'' NPT or M25 conduit hubs. Label content can be customized (labels in various languages and with different exit signs are available).
